High Precision HV Circuit Breaker Analyzer for Mechanical & Electrical Testing

Name: High Precision HV Circuit Breaker Analyzer for Mechanical & Electrical Testing
Brand: Guangzhou HongCe Equipment Co., Ltd.
SKU: HCST-001
Price: 5,000.00 USD
Availability: InStock

Marka Adı:	HongCe
Model Numarası:	HCST-001
Moq:	1 set
fiyat:	Anlaşılabilir
Ödeme Şartları:	L/C, T/T
Tedarik Yeteneği:	Ayda 30 Set

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

Çin

Sertifika:

Calibration certificate(cost additional)

Ambalaj bilgileri:

Kontrplak

Ürün Açıklaması

High-Precision HV Circuit Breaker Analyzer for Mechanical & Electrical Testing

Product Introduction

The HCST-001 High Voltage Switch Tester is an integrated testing device for mechanical characteristics, electrical performance, and motion analysis. It simultaneously performs high-precision time measurements on 6 main contacts and 6 auxiliary contacts, supports closing resistor testing, travel and speed analysis, automatic operation tests, and report generation. Equipped with dual adjustable AC/DC power supplies, it is suitable for on-site testing and diagnostics of various high-voltage switchgear.

Product Features

Supports 6-channel main/auxiliary contact timing measurement (closing, opening, bounce, non-synchronism, etc.)
High-precision analog and digital sensor inputs for travel, angle, and speed measurement
Dual independent adjustable AC/DC control and motor power supplies
Built-in current sensors for real-time coil and motor current monitoring
Supports 10,000 automatic operation endurance tests
Data pre-storage to prevent loss, USB export and software upgrade support
Automatically generates Word test reports with waveforms, logos, and data tables
Electronic switch control for long life and high accuracy
Manual and automatic voltage adjustment modes
Complies with IEC 62271 and other international standards

International Reference Standards

Standard Number	Standard Name and Clause Description
IEC 62271-100	High-voltage AC circuit breakers - Mechanical operation and electrical performance testing
IEC 62271-102	High-voltage AC disconnectors and earthing switches - Mechanical and electrical characteristics
IEC 60068-2-6	Environmental testing - Vibration tests
IEC 61010-1	Safety requirements for electrical equipment for measurement, control, and laboratory use

Product Applications

Regular maintenance of high-voltage switchgear in power plants and substations
Factory acceptance testing and inspection of circuit breakers and isolators
On-site testing and services by power maintenance companies
Research analysis in laboratories and scientific institutions
Teaching and demonstration in electrical training institutions

Technical Parameters

Parameter Item	Technical Specification
Time Measurement Range	1～20000ms
Time Measurement Accuracy	±(0.05%t + 0.1)ms
Analog Sensor Input Range	0～5V
Analog Sensor Resistance Range	50Ω～5kΩ
Digital Sensor Interface	RS422 (Long-line Driver)
Angle Measurement Accuracy	±0.1º, Resolution 0.05º
Travel Measurement Range	Up to 1000mm, Resolution 0.1mm
Travel Measurement Accuracy	±(0.5%L + 0.2)mm
Speed Measurement Range	0～20m/s, Resolution 0.01m/s
Control Power Output	0～270V/10A (AC/DC)
Motor Power Output	0～250V/20A (AC/DC)
Voltmeter Measurement Range	0～300V, Accuracy ±(0.5%U + 1)V
Coil Current Measurement	0～20A (DC/AC Peak), Resolution 10mA
Motor Current Measurement	0～20A (DC/AC Peak), Resolution 10mA
Closing Resistance Range	50～2000Ω, Accuracy ±(1%R + 1)Ω
Output Control Power	DC/AC 300V/30A
Operating Power Supply	198～264VAC, 47～63Hz
Operating Environment	-10～50℃, Humidity ≤90%RH non-condensing
Dimensions	1450×600×800mm
Weight	70kg
