High Precision Tensile Strength Testing Machine with 6 Stations and 0~40A Load Current for Cable and Wire Testing

High Precision Tensile Strength Testing Machine with 6 Stations and 0~40A Load Current for Cable and Wire Testing

Marka Adı:	HongCe
Model Numarası:	HDX1314
Moq:	1 set
fiyat:	Negotiatable
Ödeme Şartları:	T/T
Tedarik Yeteneği:	ayda 20 takım

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

ÇİN

Sertifika:

Third part calibration certificate(cost additional)

Standart:

UL817

İstasyonlar:

Yük akımı:

0 ~ 40A, keyfi ayarlanabilir

Yük Gerilimi:

4~12V

Garanti:

1 yıl

Ortam sıcaklığı:

0 ~ 40 ℃

Ortam nemi:

%85'ten az Rh

Test süresi:

0.1~999.9S

Ambalaj bilgileri:

Kontrplak

Vurgulamak:

6 Stations Tensile Strength Testing Machine

0~40A Load Current Pull Force Tester

4~12V Load Voltage Cable and Wire Tester

Ürün Açıklaması

Cable and Wire Tensile Strength Testing Machine

High Precision Pull Force Tester for Electrical Cables & Wires – UL 817 Standards Compliant

The Cable and Wire Pull Strength Tester is a high-precision device designed to evaluate the mechanical strength of plugs, connectors, and cables. By simulating real-world scenarios such as sudden pulls, rotations, and lifting loads, it ensures that wires, cables, and their connected components remain securely connected under stress, effectively preventing accidental disconnection.

Widely used in plug production lines, quality inspection laboratories, and power cable manufacturing, it is an ideal testing solution for ensuring the mechanical safety of electrical products.

International Reference Standards

UL 817: Requirements for sudden pull strength, rotational testing, and current load testing of plug and cord assemblies (UL817 No. 99.1-99.2 "Turning test", No. 100.1-100.3 "Sheath retention test")
ANSI/EIA 364-38B: Specifies a test procedure for the axial pull of cable clamps on electrical connectors to evaluate their tensile retention capabilities
IEC 60794-1-311:2024: Test method for tensile strength and elongation of optical fiber cable components (Method G11A)
EN 50289-3-16: Mechanical test standard for telecommunication cables, covering laboratory methods for determining the tensile properties of cables

Test Objects and Inspection Items

Applicable Objects

Power plugs, connector terminals
Household appliance cables (e.g., rice cooker, washing machine power cords)
Communication cables (network cables, fiber optic cables)
Automotive charging station cables (QC3.0 fast charging device cables)

Testable Items

Sudden tensile strength: Tests the connection strength between the plug and the conductor under simulated sudden tensile forces
Rotational fatigue: Tests the cable's durability under torsion
Current load performance: Verifies connection stability after applying current (e.g., 30A/12V)
Elongation and breaking strength: Analyzes the mechanical behavior of the cable as it stretches and deforms to fracture

Technical Parameters

Parameter	Specification
Power supply	AC 220V 50Hz
Load current	0~40A, Arbitrary adjustable
Load voltage	4~12V
Working station	6 stations
Test times	1~9999 times, can be preset
Test time	0.1~999.9S
Load weight	2.5 pound(lb), 3 pound(lb), 15 pound(lb) 6 pcs per each
Ambient temperature	0~40℃
Ambient humidity	less than 85%Rh
Reference standard	UL817 clause 99.1-99.2 Abrupt Pull Test, clause 100.1-100.3 Jacket retention test

Product Images
