360° Rotation Adjustable Light Fitting for Precision Lamp Testing with Lighting Adjustment Device

360° Rotation Adjustable Light Fitting for Precision Lamp Testing with Lighting Adjustment Device

Marka Adı:	HongCe
Model Numarası:	HDJ0008
Moq:	1 takım
fiyat:	Negotiatable
Ödeme Şartları:	T/T,L/C
Tedarik Yeteneği:	10 set /ay

Ayrıntılı Bilgiler

Ürün Açıklaması

Ayrıntılı Bilgiler

Menşe yeri:

Sertifika:

calibration certificate (cost additional)

Garanti:

1 yıl

Ürün adı:

Aydınlatma Ayar Cihazı Test Cihazı

Modeli:

HDJ0008

Eylem dönme açısı:

0-360 °

Denetleyici:

Mitsubishi plc

Dokunmatik ekran arayüzü

İngilizce

İsteğe bağlı

Ambalaj bilgileri:

Kontrplak

Vurgulamak:

360° Rotation Light Testing Equipment

Adjustable Light Fitting Lighting Adjustment Device

Precision Lamp Testing Lamp Testing Device

Ürün Açıklaması

Adjustable Light Fitting Positioning & Angle Alignment Device for Precision Lamp Testing

Professional Light Testing Equipment for LED, Luminaires & Optical Performance Evaluation

The HDJ0008 Adjustable Light Fitting Device is designed to simplify and standardize lamp positioning during optical and performance testing. Built by HongCe, a trusted original manufacturer in China, this device ensures consistent angle alignment, stable mounting, and precise positioning for a wide range of lighting products—from LED bulbs to indoor and industrial luminaires. It is an essential component for professional Light Testing Equipment setups.

Key Features

Flexible Angle Adjustment — Smooth rotation and tilt control for accurate test positioning
Stable Mounting Structure — Ensures zero vibration during photometric measurement
High-Precision Scales — Laser-marked angle indicators for repeatable alignment
Universal Lamp Compatibility — Supports LED bulbs, tubes, downlights, panels, luminaires, and more
Durable Industrial Construction — Long service life with minimal maintenance
User-Friendly Operation — Designed for quick installation and adjustment without special tools

Technical Specifications

Parameter	Value
Test rate	0.1 to 10 times/min (adjustable)
Bending angle	0-180°
Rotation center height	1200mm
Maximum radius of gyration	R500mm
Maximum stroke of stretching action	0-650mm
Action angle of rotation	0-360°
Test cycles	1-999999 (adjustable)
Drive motor	Servo motor
HMI	Touch screen interface
Load	With terminals, externally connected to load (optional additional cost)

Compliance with International Standards

IEC/EN Standards
IEC 60598-1 - General requirements for luminaires
Clause 4.12 Mounting requirements
Clause 12 Mechanical strength
IEC 62722-2-1 - LED luminaires performance testing
Clause 6.2 Test conditions
Clause 7.3 Mounting and orientation
IEC 62471 - Photobiological safety
Sample positioning guidelines
IEC 61010-1 - Laboratory equipment safety
IES LM-79 - Luminous flux & electrical testing
Orientation and mounting specifications
